AJR UV 10000+EU (3x blacklight + 1x brightlight) - ASML 12NC 4022.479.00764
The AJR UV 10000+EU (3x blacklight + 1x brightlight) inspection lamp is specifically designed for use in critical, low-dust working environments and offers a reliable method for detecting particle contamination.
The AJR UV 10000+EU (3x blacklight + 1x brightlight) is a powerful inspection lamp specifically developed for the accurate detection of contamination and particles in critical cleanroom environments. Through the integration of three UVA light sources and one bright white light source, imperfections that are invisible to the naked eye can be efficiently identified.
Accurate inspection and ergonomics
This inspection lamp is designed for long-term use by professionals in cleanroom technology. Thanks to the low weight and ergonomic design, physical strain during extensive checks is minimised. The lamp features an ASML 12NC registration, which underscores its suitability for high-end technical environments. With the included extra battery, continuity during the working day is guaranteed.
| Light source | 3x 365nm +/-3% (UVA) LED 1x White LED (1500 LUX) |
|---|---|
| UV intensity | 1000uW/cm² |
| Dimensions | 157 mm (L) 76 mm (D) 177 mm (H) |
| Weight | 498 grams (including battery) |
| Battery capacity | 2200 mAh (12.6V) |
| Runtime | 3-4 operational hours |
| Charging time | approx. 2 hours |
| LED lifespan | 30,000 hours |
| Power supply | 100 - 240 V (50 - 60 HZ) |
| Housing material | Plastic |
| ASML 12NC | 4022.479.00764 |
| Warranty | 1 year on electrical components |
Application areas and accessories
The AJR UV 10000+EU is widely applicable in the high-tech industry, electronics, and healthcare. The lamp is also suitable for ASML Grade 4 and 2 inspections when equipped with the optional blacklight filter. For use in strictly controlled environments, a special carrying case is available with a 3D-printed insert to prevent foam contamination.
Consult the product datasheet for detailed instructions on maintenance and optional accessories. For optimal safety, the included UV inspection glasses must always be worn during the use of the UVA light sources.
Do you have technical questions about the AJR UV 10000+EU (3x blacklight + 1x brightlight) or would you like to know more about our inspection solutions? Contact one of our product specialists for personal advice.
